1-6
Chapter 1 Installation of the Unit System Construction
Connecting the Super Unit, Input Box, DS-8007
Connect the main unit and the HS Adapter (HSA-80 series) or DS-8007 Adapter (DSA-82) with module connection
cable (CJO-08SSxx).
When using the Input Box (IB-8004), connect the main unit and Input Box with module connection cable and
connect the HS Adapter to the main unit via Input Box.
Make sure that the power is turned OFF when connecting or disconnecting the cable.
The following cables of different length are available according to the different arrangement of main unit and HS-
8000/DS-8007, main unit and Input Box.
For details of the specification and monitoring performance of the DS-8007 system, refer to the operation manual of
the DS-8007 system.
When connecting the module connection cable, press the connector, tighten the screw with
hand and secure it with flat-blade screw driver. If the connection is not secure, contact failure
may occur.
When the DS-8007 is connected to the DS-8500 system using the DSA-82, a voltage drop
may occur depending on the cable connection condition which causes the charging process
to temporarily cease or cease before completion.
Model Length
CJO-08SS0.3 0.3m
CJO-08SS1.5 1.5m
CJO-08SS3.5 3.5m
CJO-08SS5 5m
CJO-08SS10 10m
