Fukuda DS-8500 - Periodic Check Items and Procedures

9-4
Chapter 9 Maintenance Check Daily and Periodic Check
Periodic Check Items and Procedures
Perform the periodic check according to the following list.
 The periodic check should be performed once a year.
 The "Periodic Check List" is on the last page of this manual.
 If the equipment fails any check item on the periodic check list, the general judgment will be "Fail". Repair the
equipment so that it passes all the check items.
 Use the equipment only if the judgments for all the items are "OK".
 Check all cables, equipments, accessories, earth impedance, leakage current, and accuracy.
CAUTION
 Before the check procedure, back up the setup data and patient data on a CF card.
 Some models of commercially available bench top functional testers and patient simulators
can be used to verify the proper functionality of SpO
2
monitoring system, sensors, cables,
but they are incapable of properly evaluating the SpO
2
measurement accuracy. SpO
2
measurement accuracy can only be evaluated by comparing measurement data with SaO
2
measurements obtained from simultaneously sampled arterial blood using a laboratory Co-
oximeter.
No. Check Items Check Procedure Criteria
1. External Appearance/Accessories
01 External Appearance Visually check the exterior for scratch, crack,
deformation, and rust.
No scratches, cracks, deformation, and rust
should be found on the exterior.
02 Cables Check that neither damage nor broken wire is
found in all cables.
Neither damaged nor broken wire should be
found.
03 Printing Paper Visually check the installed condition. The paper should be correctly installed.
04 Operation Manual Check that accompanying documents
(operational manual, etc.) are stored in specified
location.
Should be stored in specified location.
No Check Items Check Procedure Criteria
2. Power Supply
01 Main Power Supply
Switch
Check by connecting the power cable to AC and
turning the power supply switch ON/OFF.
Check that the power supply LED lights.
02 Fuse Remove the fuse from the fuse holder, and
visually check the model type and current
capacity.
The specified fuse indicated on the
equipment should be used.
No Check Items Check Procedure Criteria
3. Display/Operation/Print
01 Check Labels Visually check the rating label and caution label
of the equipment.
Should be neither peeled nor stained nor
unclear.
02 Operation, Switch Check by operating the switches and touch
keys.
Should operate correctly.
03 LCD Unit Check that the home display is displayed on the
LCD.
Characters and waveform should be clear.
The display should be clearly displayed with
sufficient brightness.
04 Alarm Indicator Check if the alarm indicator lights when the
power is turned ON.
The 3 segments should light in red, white,
and red when the power is turned ON.
05 Alarm Sound/
Operating Sound
On the "Tone/Volume" menu, check the alarm
sound.
Alarm sound should generate with proper
volume. There should be no beat noise.
