2-6
Chapter 2 Network System Construction Wireless Network
tabular trend will not be displayed, and Σ recording cannot be performed. For the ST
display, overlap waveform will not be displayed on the DS-5800N/NX/NX
MB
until 15
minutes have passed since the reference waveform is set on this monitor.
 The ST display on the central monitor will be distorted when the ECG lead (ECG1 or ECG
2) is changed on this monitor. Redrawing the ST display will return the display to normal.
NOTE
 If the numeric data is displayed as "xxx" (out of measurement range) on this monitor,
maximum or minimum value of measurable range will be transmitted to the central monitor.
Wireless Network
In this section, connection and setup procedure for wireless (telemetry) network is explained.
By constructing a wireless network using the telemetry transmitter module (HLX-801 (FA), HLX-801 (G)), the data
on this bedside monitor can be transmitted to the central monitor.
WARNING
 Some wireless combinations of telemetry transmitters may generate interference with other
devices.
 Before selecting the channel, verify it will not interfere with other channels.
 Make sure the telemetry manager of your system is aware of any changes to the telemetry
channels.
 If transmitters are used in a neighboring medical facility, your facility and the neighboring
facility must make agreements on the setting of the telemetry channels to prevent telemetry
interference.
Example of Wireless Network Construction
CAUTION
 The setup of channel ID and group ID should be performed only by our service
representative. Users should not perform this procedure as malfunction may occur.
Value Outside the
Measurement Range
Central Monitor Display
HR 301 bpm and above 300 bpm
Respiration Rate 151 Bpm and above 150 Bpm
Blood Pressure –51 mmHg and below
301 mmHg and above
-50 mmHg
300 mmHg
Temperature -0.1°C/31.8°F and below
45.1°C/113.2°F and above
0°C/32.0°F
45.0°C/113.0°F
Pulse Rate
(Masimo Unit)
240 bpm and above
25 bpm and below
239 bpm
26bpm
Pulse Rate
(Nellcor Unit)
251 bpm and above 300 bpm
