Chapter 4 Connection to the External Devices SvO2/CCO Monitor Connection
External Device Setup
To monitor the ventilator alarm, it is necessary to select the ventilator type to be connected.
REFERENCE
 Refer to the following procedure. (

"External Device Setup" P4-16)
SvO
2
/CCO Monitor Connection
This section describes the procedure on how to connect the DS-8500 System to the oximeter /CCO measurement
device (Vigilance, VigilanceCEDV, VigilanceII, Vigileo, EV1000) manufactured by Edwards Lifescience, and
hemodynamic monitoring device (PiCCO or PulsioFlex).
By connecting the SvO
2
/CCO Monitor to one of the following ports, SvO
2
/CCO Monitor data can be monitored on
the DS-8500 System.
*COM1 to COM4 port on the main unit
*Status II port on the main unit
*Multiport Module HP-800
*1
: To connect the PulsioFlex PC4000, USB to RS-232C connector cable (UC-232A, ATEN) specified by PULSION
Medical Systems is required.
Make sure that the network for the Vigilance/Vigileo is set as follows.
For procedure to check the Vigilance/Vigileo network setting, refer to the operation manual for the Vigilance/
Vigileo.
Device : IFM Out
Baud Rate : 19200bps
Parity Bit : None
Stop Bit : 1
Data Bit : 8
Flow Control : 2 sec.
Make sure that the network for the PulsioFlex is set as follows.
For procedure to check the PulsioFlex network setting, refer to the operation manual for the PulsioFlex.
RS-232C Protocol : PulsioFlex V1.0
CAUTION
 When connecting this system and the SvO
2
/CCO monitor, use only the specified connection
cable.
SvO
2
/CCO Monitor
Connection Cable
For STATUS II Connector For Serial Connector
Vigilance CJ-406RI-70Vigi (x1) CJO-04RS4 (x1)
Vigilance CEDV CJ-406RI-70Vigi (x1) CJO-04RS4 (x1)
VigilanceII CJ-402RI-70SVi (x1) CJ-502 (x1)
Vigileo CJ-402RI-70SVi (x1) CJ-502 (x1)
EV1000 CJ-406RI-70Vigi (x1) CJO-04RS4 (x1)
PiCCO CJO-19RS5 (x1) CJO-18RS5 (x1)
PulsioFlex - CJ-725 (x1)
*1
