4-17
Chapter 4 Connection to the External Devices Setup for the External Device Connection
Ventilator and MGU-810 cannot be used simultaneously.
When MGU-810 is selected, a ventilator cannot be assigned to Status II or HP-800.
When MGU-800 series is not connected, and HR-800 is directly connected to the main unit,
select [OFF] for "U-LINK".
If the setting is other than [OFF], printing on the HR-800 cannot be performed.
When using the BISx, BIS Monitor data cannot be input.
By performing the setting for the HP-800, the setting stored on the HP-800 can be used by
inserting the HP-800 to other slot of the Input Box or connecting it to other DS-8500 system.
For the HP-800 and the main unit port, the setting needs to be different.
Make sure to power cycle the main unit when the HP-800 setting is changed.
When [Magnetic Card] is selected, perform further settings on the "Magnetic Card Reader"
setup menu.
When [HLX] is selected, perform telemetry setup (channel ID, etc.) on the "Telemeter" setup
menu.
The external device parameters to be displayed on the graphic trend/tabular trend needs to
be selected in advance on the "Trend Data Setup" window ([Data Review>Graphic Trend or
Tabular Trend] or [Initial Settings>External Device>Main Unit/HP-800]).
When [TCM4/TCM5] is selected, only TCM4, TCM5 FLEX can be connected. Other TCM
series device cannot be connected.
Unit Module Setup
Multiparameter Connector Setup
On the "Multiamplifier" setup menu, the parameter to measure on each multiparameter connector can be set.
When the Input Box is not connected, the measuring parameters will be automatically set by connecting the relay
cable to the multiparameter connector on the HS-8000 or DS-8007.
If the Input Box is connected with the HM-800 Multi Module, it is necessary to manually set the measuring parameter
for each multiparameter connector.
When the DS-8007 is used, the temperature measured on temperature jack is fixed as T1,
T2.
1Press the [Menu], [Initial Settings], [System], [Unit Module] keys.
