Chapter 4 Connection to the External Devices Ventilator Measurement and Alarm Input
Chapter 4 Connection to the External
Devices
Ventilator Measurement and Alarm Input
A ventilator can be connected to the DS-8500 system using the Status II port on the main unit or via Multiport
Module (HP-800) connected to the Input Box.
By connecting a ventilator, ventilator measurement data and alarm can be monitored on the patient monitor.
Also, ventilator alarm can be notified to the central monitor via wireless and wired network.
This section describes the procedure to connect the DS-8500 system and ventilator, and to input the ventilator
measurement and alarm.
When connecting a ventilator, check the corresponding software version of the ventilator.
Ventilator
Connection Cable
For Connection to DSC-8500
Status II/HP-800
Servo Ventilator 900C/900D/900E
*
CJ-400RI-70SV9 (x1)
Servo Ventilator 300/300A CJ-401RI-70SV3 (x1)
Servo Ventilator
SERVO-i/SERVO-s/SERVO-U/SERVO-n/
SERVO-air
CJ-402RI-70SVi (x1)
PURITAN-BENNETT Ventilator 740/760 CJ-403RI-70PB (x1)
PURITAN-BENNETT Ventilator 840 CJ-403RI-70PB (x1)
Drager Medical Ventilator
Evita 2 dura/Evita 4/Evita XL
CJ-402RI-70SVi (x1)
VELIA/ASTRAL CJO-23DR2
VS ULTRA CJO-24DR2
* For the SV-900 series, only the alarm can be input.
Ventilator Corresponding Software Version
Servo Ventilator 900C/900D/900E Not specified
Servo Ventilator 300/300A Not specified
Servo Ventilator SERVO-i v1.5 / v2.0 / v3.0
Servo Ventilator SERVO-s v2.0 / v3.0
Servo Ventilator
SERVO-U/SERVO-n/SERVO-air
v1.0
PB740 M
PB760 H
PB840 K
Evita 2 dura 04.14
Evita 4 04.14
Evita XL 05.10
VELIA/ASTRAL Not specified
VS ULTRA Not specified
