4-2
Chapter 4 Connection to the External Devices Ventilator Measurement and Alarm Input
WARNING
 If the DS-8500 system does not generate an alarm even though the ventilator is generating
an alarm, or if any other malfunction occurs, immediately check the ventilator, this
equipment, cable, and replace the cable if necessary.
 The alarm generation on this system is not guaranteed if the alarm other than the following
generates at the ventilator.
SV-900:
gas supply alarm, power failure alarm, expiratory minute volume alarm, airway pressure
upper limit alarm, apnea alarm, O
2
concentration alarm
SV-300:
airway pressure upper limit alarm, high continuous pressure alarm, O
2
concentration
lower limit alarm, expiratory minute volume upper/lower limit alarm, apnea alarm, gas
supply alarm, air supply alarm, O
2
supply alarm, battery alarm, limited battery alarm, no
battery alarm, overrange alarm
SERVO-i:
airway pressure upper limit alarm, high continuous pressure alarm, O
2
concentration
lower limit alarm, expiratory minute volume upper/lower limit alarm, apnea alarm, gas
supply alarm, O
2
supply alarm, battery alarm, no battery alarm, limited battery alarm,
overrange alarm, expiratory cassette disconnected alarm, backup ventilation alarm,
regulation pressure limited alarm, respiratory rate alarm, PEEP low alarm, EtCO
2
upper
limit alarm, EtCO
2
lower limit alarm
SERVO-s:
airway pressure upper limit alarm, high continuous pressure alarm, O
2
concentration
lower limit alarm, expiratory minute volume upper/lower limit alarm, apnea alarm, gas
supply alarm, air supply alarm, O
2
supply alarm, backup ventilation alarm, respiratory
rate alarm, PEEP low alarm
SERVO-U/n/air:
airway pressure upper limit alarm, expiratory minute volume upper/lower limit alarm,
apnea alarm, gas supply alarm, air supply alarm, O
2
supply alarm, overrange alarm,
respiratory rate alarm, PEEP low alarm, battery operation
PB 740/PB 760/PB 840:
The PB740/PB760/PB840 acquires alarm information from the nurse call port. The
ventilator alarm that cannot be acquired from the nurse call port is not guaranteed. For
corresponding alarm, refer to the service representative of the ventilator manufacturer.
 This equipment is not compatible to the following alarms generated on the Evita 2 dura/Evita
4/Evita XL.
 O
2
monitoring disabled alarm, CO
2
alarm disabled alarm, Oximeter alarm disabled
alarm, Neo. volume measurement inoperable alarm, Minute volume alarm disabled
alarm, Minute volume alarm low off alarm, Tidal volume alarm high off alarm, Apnea
alarm off alarm, Nebulizer active alarm
 When the Evita 2 dura/Evita 4/Evita XL is connected, there is a communication delay of 3
seconds between the DS-8500 system and the Evita ventilator.Therefore, if the alarm
generated at the ventilator is resolved within 3 seconds, the ventilator alarm may not be
generated at the DS-8500 system.
 When connecting the VELIA, ASTRAL, VS ULTRA, refer to the respective operation
manual, and check which ventilator alarm will be output.
 When the VELIA, ASTRAL, VS ULTRA ventilator is connected, and the ventilator power is
turned OFF, alarm will not generate on the DS-8500. If the connection cable is disconnected
from the ventilator, <Vent. Alarm> will generate, but <VENT_COMM> alarm will not
generate on the DS-8500.
