4-10
Chapter 4 Connection to the External Devices BIS Data Input
CO
2
Source Priority
When MGU-800 and HS-8000 or DS-8007 are connected simultaneously, the CO
2
source to prioritize the
measurement can be set.
REFERENCE
 The setup can be performed on the "Gas" menu.
(

Operation Manual "Multigas Unit Data Setup (Multigas Concentration/Spirometry)" P7-
86)
Multigas Unit/ Spiro Unit Selection
To display the Multigas Unit gas concentration data, the type of Multigas Unit, Spiro Unit needs to be selected.
REFERENCE
 Refer to the following procedure. (

"External Device Setup" P4-16)
BIS Data Input
By connecting the A-2000/A-3000 BIS monitor (Covidien), the patient's recovery from anesthesia can be verified
by BIS (Bispectral Index) value.
By connecting the BISx (Covidien), the patient's recovery from anesthesia can be verified by BIS (Bispectral Index)
value.
CAUTION
 Refer to the BIS monitor operation manual and set the SQI value above 15.
 When using the BIS monitor, ASCII should be set to communicate with this system. Make
sure that ASCII is set on the BIS monitor communication setting. Refer to the BIS monitor
operation manual for procedures.
 When using the BIS monitor, securely connect the connection cable to the serial or status
connector of the main unit or the STATUS II connector of the HP-800.
 When using the BIS monitor and BISx at the same time, the data display of BISx will be
prioritized.
BIS Monitor
Connection Cable
For Status II Connector For Serial Connector
A-2000
CJ-407RI-70BIS CJO-03RS4
A-3000
