2-5
Chapter 2 Network System Construction Wired Network System
Precautions about the DS-LAN
Precautions Common for the DS-LAN II/DS-LAN III Network
If the "RR/APNEA Alarm Source" setting is other than [Impedance] (or, if [Auto] selects a
setting other than [Impedance]), the RESP waveform will not be transmitted on a wired
network.
If the "RR Alarm/APNEA Source" setting is other than [CO
2
] (Or, if [Auto] selects a setting
other than [CO
2
]), the CO
2
waveform will not be transmitted on a wired network.
For the numeric data displayed as "xxx", maximum or minimum value of measurable
range will be transmitted.
The numeric data displayed as "--- " will be treated as not measured data.
If the measurement unit of CO
2
concentration is mmHg and [99 mmHg] is selected for
"Upper Limit of CO
2
(mmHg) Transmission" under [Initial Settings>System>DS-LAN or
Telemeter), the CO
2
value of 100 mmHg or above will be transmitted as 99 mmHg.
As this monitor do not have the arrhythmia template display and 12-lead ST display
function, these display on the central monitor will not be corresponded.
When connected to a wired network, the time/date will synchronize with the central
monitor. In this case, the time/date cannot be changed on this monitor.
On the central monitor, the respiration waveform and RR value based on the "RR/APNEA
Alarm Source" selected on this monitor will be displayed. The same parameter for the RR
and apnea will be monitored on this monitor and the central monitor.
The alarms that can be notified to the central monitor depend on the model type and
software version of the central monitor. For details, refer to the operation manual of the
central monitor.
Precautions about the DS-LAN II Network
The BP measurement unit should be set to "mmHg".
The data cannot be output to the AU-5500N.
When the BP measurement unit is "kPa", BP waveform, BP numeric data, NIBP numeric
data, NIBP list will not be transmitted. It will be treated as not measured data, and will not
be displayed on the central monitor. Also, the alarm limit setup from the central monitor
cannot be performed.
The following arrhythmia alarms cannot be transmitted.
TACHY, BRADY, COUPLET, PAUSE, TRIGEMINY, TRIPLET, EXT TACHY, EXT
BRADY, R on T, MULTIFORM, VENT RHYTHM, SVT, IRREGULAR RR, PROLONGED
RR, S FREQUENT, S COUPLET, VPC, SVPC, PACER NOT CAPTURE, PACE NOT
PACING
Arrhythmia alarm of "Slow_VT" will be transmitted as "VT" .
On a wired network, waveform, numeric data, and alarm of TEMP3 to 8 will not be
transmitted. Also, the displayable waveform, numeric data, alarm differs depending on
the connected central monitor. Refer also to the operation manual for the respective
central monitor.
The numeric data and alarm of PR_IBP will not be transmitted to the central monitor.
Even if the PR_IBP alarm is generated on the DSC-8500, this alarm will not be generated
on the central monitor.
When the DS-5800N/NX/NX
MB
is used as a central monitor, recall, graphic trend, and
