1-2
Chapter 1 Installation of the Unit System Construction
chemicals may enter the equipment and cause damage. For the recorder unit, it may also cause paper jam.
If the equipment is used under an environment not fulfilling the specified condition, not only
that the equipment cannot deliver its maximum performance, the equipment may be
damaged and safety cannot be ensured.
If using in an environment other than specified above, contact your nearest service
representative.
Equipotential Grounding
When connecting multiple equipments, electrical potential difference may be generated
between the equipments. This may result in electric shock to the patient connected to
these devices. Pay special attention for use in operating room, ICU, CCU, cardiac
catheter laboratory, and cardiovascular X-ray room. To avoid such electrical potential
difference, use the ground cable to connect each equipment's potential equalization
terminal to the same ground terminal. This is called equipotential grounding.
System Construction
This section describes the connection procedure of this equipment.
Connect the Main Unit (DSC-8500 series) with necessary units such as Display Unit (LC-8019T/LC-8019TC/LC-
8015T/LC-8015TC), Super Unit (HS-8000 series), DS-8007 System, Input Box (IB-8004), etc.
Connection with the Display Unit
When lifting this equipment, hold the bottom part of the main unit and not the display unit.
When connecting the display unit to the main unit, make sure to secure them with screws.
When turning ON the power for the first time after the display unit and the main unit is
connected, the display may scintillate. This is a normal operation of the display unit and not
a malfunction.
1Lay a soft cloth on a table to protect the LCD, and place the display unit facing downwards.
Place the display unit so that it will not apply force to the jog dial.
To Next Page
