1-5
Chapter 1 Installation of the Unit System Construction
2Place the DS-8007 on the center of the DSA-82, and slide it along the rail in the arrow direction until it is
securely connected.
When disconnecting the DS-8007, unlock the release lever, and slide the DS-8007 along the rail in the arrow
direction.
3By connecting the HS-8000 (HSA-80) to the
DS-8007 (DSA-82) using the module
connection cable (CJO-08SSxx) , the using
unit can be switched.The selection of which
unit to use on the host monitor can be made
by DS-8007/HS-8000 Switch.
1 CJO-08SSxx
2 HS-8000
3 HSA-80
