8-6
Chapter 8 Cleaning/Disinfecting/Storing Cleaning the Equipment and Sensors
26 hours (@120 mL/min.)
45 hours (@70 mL/min.)
1Remove the water trap by pressing and holding the release button on the holder part.
2Unscrew the reservoir from the filter to separate them
3Empty the reservoir.
WARNING
 The contents of the water trap should be handled as a potential infection hazard.
4Screw back the reservoir and reattach the water trap
