5.3 Porthole Door Replacement
Refer to “Figure 6-6 Side Panel (East/West)”.
1. Use a at edge screwdriver to pry o the hinge cover.
2. Open the door to unload the springs.
3. Slide the hinge pin down, out the hole at the bottom of the hinge.
4. Remove the porthole door.
5. Now the door springs can be accessed along with screws that secure the inside half of the hinge cover.
6. To replace the porthole door, put the door back in place in the open position, install the springs, then slide
the hinge pin back in place.
7. Close the door and snap the hinge cover back in place, keeping the thin side of the cover closest to the
porthole.
5.4 Right Rail Assembly Repair Procedures
NOTE: The entire rail assembly is available or the individual parts may be replaced. Refer to Chapter 6 for part
numbers.
5.4.1 Removing the Right Upright (Motor Side)
Refer to “Figure 5-1 Heater Housing Cover and Sot”, “Figure 5-24 Disconnecting Heater Door Cable”, “Figure
5-25 Upright Decorative Strips, End Caps, and Wire Covers”, “Figure 5-26 Removing the Lift Motor”, “Figure 5-27
Display Module Disassembly”, and “Figure 5-34 Re-attaching the Upright”.
90 6600-0343-000 104 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 5: Repair Procedures
