Scale R Select from 2 scale resolution settings; 10 grams or 5 grams (10 grams is the factory default).
Comfort Allows you to remove the Comfort Screen feature.
Set Time
Set real time clock for time, day and date. Choose how date is displayed (North American or European).
Choose a 12 hour (AM/PM) or 24 hour time display.
View Mods
Display the current software revision of the options installed on this speciîš¿c unit (Humidiîš¿er, Scale, SPO2,
etc.)
Down Go to second service screen.
Figure 4-2 Second Service Screen
Up Return to previous screen.
Status
Check status of all self test the software
runs continuously. These include: incubator
heater on (INCHTRON), warmer heater on
(WRMHTRON), incubator/warmer heater
oî º (I/WHTROFF), humidiîš¿er heater on
(RHHTR), remote monitoring data stream
(RS232LOOP), incubator fan on (FANON), and
incubator fan oî º (FANOFF).
If the RS232 option is not installed
RS232LOOP will display N/A. To test the
circuit if the option is installed, short pins 2
and 3 on the 9 pin connector on the back of
the electrical enclosure.
Figure 4-3 Status Menu
Switches
Select to bring up a diagnostic diagram of the unit that displays the status of all the switches. If the circle
next to the switch is lit, the switch is closed; if it is not lit, the switch is open. Also, while the switch status
screen is active, you can hold down the alarm silence button to light the alarm light, system failure light
and all LED segments to test them.
© 2001 by Datex-Ohmeda, Inc.. All rights reserved. 6600-0343-000 104 31
Chapter 4: Troubleshooting
