Chapter 2: Service Checkout
2.1 Setup
The OmniBed is shipped with the canopy in the locked down position. Before the canopy can be raised the rail
shipping locks must be released. They are located in both sides of the OmniBed near the outside bottom of the
uprights. An orange tear-away label marks their location. The lock consists of a socket head cap screw in a slot.
Tightening the screw disengages the screw head from the slot and releases the lift rail. Using the 4 mm hex
key provided with the unit, turn the screw clockwise about 8 rotations until the screw securely seats in its hole.
Remove the tear away label.
WARNING:
Do not perform the preoperative checkout procedure while the patient occupies the unit.
WARNING:
Complete the preoperative checkout procedure section of this manual before putting the unit into
operation. If the equipment fails any portion of the checkout procedure it must be removed from
use and repaired.
2.2 Mechanical Checks
1. Disconnect the power cord for the mechanical portion of the preoperative checkout procedure.
2. Examine the power cord for any signs of damage. Replace the cord if damage is evident.
3. Check that both plug retaining brackets are in place.
4. Examine the unit overall for any damaged or missing parts.
5. Check that all the casters are in rm contact with the oor and that the unit is stable. Lock the caster
brakes and check that they hold the unit in place. Release the brakes and check that the unit moves
smoothly.
6. Check the operation of the two side doors. Open the doors and check that they swing all the way down and
hang perpendicular to the bed. Check that the doors are securely attached to the unit and that the hinge
pins are properly seated. Check that the inner walls are securely fastened to the doors. Close the doors and
check that the latches hold the doors securely shut. The orange latch open indicators should not be visible
when the latches are engaged. Check that the top of the doors meet the canopy seal.
© 2001 by Datex-Ohmeda, Inc.. All rights reserved. 6600-0343-000 104 11
