6.1.9 Servo Control Oxygen
1. Screw, M4 Skt Hd ...............................................................6600-0868-402
2. Sensor housing cover ......................................................6600-1876-500
3. Oxygen sensor kit (2 pcs.)@ ..........................................6600-0120-850
4. Sensor gasket ......................................................................6600-1887-500
5. Screw, M3x10L Skt Hd .....................................................6600-0707-403
6. Split ring washer, M3 ........................................................6600-0713-402
7. Flat washer, M3...................................................................6600-0712-402
8. Screw, M2.9x16L, self tap ..............................................6600-0709-411
9. Calibration fan with harness* ......................................6600-1510-700
10. Calibration valve assembly
(includes gasket) ................................................................6600-1539-700
Calibration valve mounting screws
(2)- M4x12L Fl Hd Skt .......................................................6600-0708-409
11. Male/female shoulder screw .......................................6600-0862-400
12. Push tting, 90 degree elbow .....................................6600-0865-400
13. Chassis Vent .........................................................................6600-2017-500
14. Vent cover .............................................................................6600-2018-500
15. Vent screen ..........................................................................6600-2020-500
Vent screens (5) ..................................................................6600-0271-850
16. Washer (thin)........................................................................6600-1236-400
17. Panel hex nut .......................................................................6600-1275-400
18. M12 Split ring washer ......................................................6600-0713-408
19. Sensor housing ...................................................................6600-1875-500
20. Push tting, straight .........................................................6600-0877-400
21. Screw, M4x6L Button Hd ................................................6600-0706-407
22. Sensor housing board (also includes the board inside the
sensor housing cover) .....................................................6600-1511-700
23. Sensor plug assembly .....................................................6600-0604-700
Sensor housing assembly (includes all parts above
except item 3) ......................................................................6600-1506-700
24. Star washer, int. M4 ..........................................................6600-0713-432
Tubing (order by inch)
6mm black ............................................................................6600-0129-300
from sensors to manifold, 3.9”
from chassis vent to manifold, 3.9”
6mm white............................................................................6600-0866-400
from cal fan to manifold, 4.7”
from manifold to heatsink vent, 4.7”
*Install fan so ow arrow on side points up into chassis.
@ The date on the sensor is a discard date; the sensor should be removed from service on that date.
194 6600-0343-000 104 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 6: Illustrated Parts
