GE Giraffe OmniBed - Figure 6-42 Relay Board (6600-0214-850) Revision Level 9 or Lower

Humidier Fuse
6600-0517-602
Time lag 250V 3.15 A
(Interface board plugs
into these clips)
Supply Fuse
6600-0517-602
Time lag 250V 3.15 A
#
Board Assembly
Revision Number
Humidier Interface Board
No longer needed.
Fuse 120V 2 amp
6600-1324-602
Fuse 230V 1 amp
6600-1324-601
Figure 6-42 Relay Board (6600-0214-850) Revision Level 9 or Lower
