B.9 Weight Scale
Functional range 300 g to 8 kg
Accuracy ± 10 g
Resolution 10 g (factory setting) or 5 g (for some scales only)
NOTE: For the European Union (EU) and the European Free Trade Association (EFTA) member states in Europe,
check with your local regulations with respect to the Non-Automated Weighing Instrument (NAWI) directive as
to the process and frequency for scale calibration. The resolution of scales distributed in this EU region vary
depending on the scale revision:
• Scales with revision 2.72 only have a resolution option of 10 g.
• Scales with revision 2.86 have a resolution of 5 g up to 5000 g and 10 g up to 8000 g.
B.10 Mechanical Specications
Canopy Closed Canopy Closed Canopy Opened Canopy Opened
Bed Lowered Bed Raised Bed Lowered Bed Raised
Maximum Height 147 cm 178 cm 208 cm 239 cm
Maximum Width 69 cm
Maximum Depth (front to back) 112 cm
Maximum Weight 129 kg
B.10.1 Accessories
Maximum load
Storage drawer 7 kg
Monitor shelf 23 kg
Instrument shelf 9 kg
Total each accessory rail 23 kg
238 6600-0343-000 104 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Appendix B: Specications
