GE LOGIQ Totus

GE HealthCare CONFIDENTIAL
Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
3 - 46 Section 3-7 - Setting Up Connectivity and Tips
3-7-3-4 Network Proxy
Proxy to configure a proxy server.
Table 3-13 To Configure Add Scanner Network Properties - Proxy
Step Corresponding Graphic
1.
Navigate to Connectivity > Connection Manager > Network.
2.
Select Proxy.
3.
To use a proxy server, enable Use Proxy.
4.
When Use Proxy is enabled, in Proxy Server, enter a proxy server address of the facility.
5.
When Use Proxy is enabled, in Proxy Port, enter a port number for the proxy server.
6.
To use proxy credentials, enable Use Proxy Credentials.
7.
When Use Proxy Credentials is enabled, in Proxy User Name, enter an account user name for the proxy server.
8.
When Use Proxy Credentials is enabled, in Proxy Password, enter an account password for the proxy server.
9.
Select Done.
10.
Continue to "MyComputer Device" on page 3-47.
