Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
Chapter 3 LOGIQ Totus Setup 3 - 45
3-7-3-3 Network Wireless
Use Wireless to configure the wireless network settings.
NOTE: When the QR code is present, scan it with a smart phone to get the MAC address setting.
Table 3-12 To Configure Add Scanner Network Properties - Wireless
Step Corresponding Graphic
1.
Navigate to Connectivity > Connection Manager > Network.
2.
Select Wireless.
3.
Select Configure Wireless Network.
4.
On the Wireless Network Configuration dialog box, select the wireless connection and select Connect.
5.
When prompted, enter the new wireless network properties.
6.
Select Done.
7.
If using a proxy server, continue to "Network Proxy" on page 3-46.
