GE HealthCare CONFIDENTIAL
Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
Chapter 7 Diagnostics/Troubleshooting 7 - 21
7-3-5 Home (continued)
Connected Probes
Connected Probes shows probes connected to the LOGIQ Totus. The order on the user interface is
top down matching the left-to-right order on the LOGIQ Totus.
The information on Connected Probes is available to all service class licenses.
To access Connected Probes, navigate to Utility (second page) > Service > Home.
Figure 7-11 Connected Probes
This table shows all the elements available on Connected Probes with descriptions.
For more information :
• "Home" on page 7-15
Table 7-5 Connected Probes
Element Description
Active Probe Temperature
(Celsius)
When available, temperature of the active probe.
Not all probes report temperature. The most common probe to report temperature is
the TEE probe.
Probe Name Name of the probe connected to the LOGIQ Totus.
Probe ID Identifier of the probe connected to the LOGIQ Totus.
Serial Number
Serial number of the probe connected to the LOGIQ Totus. If the serial number of
the probe is not available, then N/A displays.
Status
Statuses of the probe connected to the LOGIQ Totus. Valid values are:
• Active
• Non Active
To Next Page
