GE HealthCare CONFIDENTIAL
D
IRECTION
5936427
, R
EV
. 1
LOGIQ T
OTUS
Basic Service Manual
8 - 64
Section 8-5 - Replacing Cables
5.
Unscrew 4 screws to remove the Unity C
able Cover
Brkt
6.
Unlock the Cable Clamp.
7.
Rotate studs of the UBE TO OPIO HUB D-SUB
15PIN Cable counterclockwise to remove the UBE
TO OPIO HUB D-SUB 15PIN Cable from the UBE.
Steps
Corresponding Graphic
389
391
