GE HealthCare CONFIDENTIAL
D
IRECTION
5936427
, R
EV
. 1
LOGIQ T
OTUS
Basic Service Manual
Section 8-7 - Replacing OPIO
8 - 127
4.
Gently pull
the T2 O
PIO Key
Rubber to
remove from
the OPIO PWA-T.
5.
Unscrew the nut to remove the 30Detent
Encoder.
6.
Pull the 30Detent
Encoder to remove
from the O
PIO
board.
7.
Unscrew the nut to remove the Joystick Enco
der
Steps
Corresponding Graphic
452
454
