DIRECTION 5936427, REV. 1 LOGIQ TOTUS Basic Service Manual
8 - 216 Section 8-11 - Replacing Options
8-11-23 Replacement of the UVSC-T
This table includes information specific to these instructions. For more information 8-2-6 "Tools needed
for servicing the LOGIQ Totus" on page 8-5 /8-2-7 "PPE Required During Service" on page 8-6.
8-11-23-1 Preparations
1.) Power off/Shutdown the system as described in 1-7-2 "Lockout/tagout procedure" on page 1-25
2.) Remove the Rear Cover Mid Assy-T as described in 8-8-10 "Replacement of the Rear Cover Mid
Assy-T" on page 8-138
3.) Remove the Rear Cover Top Assy-U as described in 8-8-17 "Replacement of the Top Cover Assy-
T" on page 8-145
4.) Remove the T2 Side Cover L Assy as described in 8-8-7 "Replacement of the T2 Side Cover L
Assy" on page 8-135
Table 8-118 Manpower, Time, Tools, and PPE
Manpower Time Tools PPE
One person Approximately 15 minutes
Phillips screwdriver
Spanner 14
Cut resistant gloves
Knee Pad
