3-46 Section 3-4 - Completing the Installation
3-4-3-9 Connections at rear of PC of System based on Dell Precision 340
Figure 3-32 Connections at rear of PC of System based on Dell Precision 340
Y-Monitor Cable
DVD IEEE 1394
Computer
Power Cable
Connection
Keyboard
Connection
Modem in 1
Mouse
Dongle
Network
USB HDD
