GE MEDICAL SYSTEMS
DIRECTION 5184024-100, REVISION 5 LOGIQWORKS BASIC SERVICE MANUAL
5-8 Section 5-3 - Block Diagrams and Theory
5-3-2-4 Theoretical Description of System based on Dell Precision 340
The Monitors receive a video signal from the PC.
Figure 5-2 Monitors Power and Signal cabling information
Video Signal
LCD (Analog)
CRT(ANALOG)
DELLPC
Monitors (CRT
or LCD)
Monitors (CRT
or LCD) Option
