3-4-1-2 Required Space for LOGIQworks Installation
Figure 3-19 Required Space for System with 1 CRT Monitor
Figure 3-20 Required Space for System with 2 CRT Monitors
min. 100
min. 80cm
recommended 100 cm
70 cm
CRT 1
Keyboard
Mouse
min. 140cm
min. 80cm
recommended 100 cm
120 cm
CRT 1
CRT 2
Keyboard
Mouse
