GE MEDICAL SYSTEMS
DIRECTION 5184024-100, REVISION 5 LOGIQWORKS BASIC SERVICE MANUAL
3-28 Section 3-4 - Completing the Installation
3-4-1-3 Weight
3-4-1-3-1 Weight of System based on Dell Precision 340
Table 3-26 Weight table of System based on Dell Precision 340
3-4-1-3-2 Transport of PC and Monitor
The weight of PC and Monitor exceeds 25lbs. To prevent injuries form carrying PC and Monitor, cut
the delivered box (See “3-2-1-1 Check of Delivered Box (cont’d)” on page 4.) and move PC and
Monitor to the installation location.
3-4-1-4 Acoustic Noise Output
max. 57dB(A)
3-4-2 Electrical Specifications
To see the Electrical Specifications for the LOGIQworks see Table 2-14 on page 2-7.
Power Consumption nominal 550 VA including all options.
.
Model Weight [kg] Weight [lbs]
Dell Precision 340
9.9 21.83
LOGIQworksw/CRT Monitor
30.5 67.24
LOGIQworksw/LCD Monitor
8.2 18.08
Modem
0.2 0.5
Table 3-27 Weight table of System based on Dell Precision 360, Dell Precision 370, on Dell
Precision 380 or on Dell Precision 390
Model Weight [kg] Weight [lbs]
Dell Precision 360
Dell Precision 370
9.9 21.83
Dell Precision 380
Dell Precision 390
17.7 39
LOGIQworks/LCD Monitor
8.2 18.08
Modem
0.2 0.5
WARNING
WARNING
Modification of voltage setting only by an authorized service person! Output power: 550VA per mains
outlet, max. power of all connected accessories must not exceed 550VA.
