IRECTION 5184024-100, REVISION 5 LOGIQWORKS® BASIC SERVICE MANUAL
Chapter 3 Installation 3-25
Section 3-4
Completing the Installation
3-4-1 System Specifications
3-4-1-1 Physical Dimensions of LOGIQworks
The physical dimensions of the LOGIQworks main parts are summarized in Table 3-25.
Table 3-27 lists the weight of LOGIQworks, with monitor and without on-board peripherals.
Table 3-24 Physical Dimension Table of System based on Dell Precision 340
Unit Description Height Width Depth Unit
DellPrecision 340
42.5 18.1 44.7 cm
17.0 7.1 17.5. Inches
Sony GDM F520
49.9 49.7 48.7 cm
19.0 19.4 19.0 Inches
NEC LCD 1880
39.4 38.7 18.0 cm
15.0 15.1 7.0 Inches
Modem
10.9 2.5 14.5 cm
4.3 1.0 5.7 Inches
Table 3-25 Physical Dimensions table of System based on Dell Precision 360, Dell Precision
370, Dell Precision 380 or on Dell Precision 390
Unit Description Height Width Depth Unit
Dell Precision 360
Dell Precision 370
42.5 18.1 44.7 cm
17.0 7.1 17.5 Inches
Dell Precision 380
Dell Precision 390
44.5 16.5 45.7 cm
17.5 6.5 18 Inches
DELL LCD 1901
39.4 38.7 18.0 cm
15.0 15.1 7.0 Inches
Modem
10.9 2.5 14.5 cm
4.3 1.0 5.7 Inches
DELL LCD 2001
39.4 38.7 18.0 cm
15.0 15.1 7.0 Inches
