GE MEDICAL SYSTEMS
DIRECTION 5184024-100, REVISION 5 LOGIQWORKS BASIC SERVICE MANUAL
6-4 Section 6-2 - Monitor Adjustment
6-2-3 Sony Triniton, GDM-F520, 21" CRT
The Sony Monitor Operating Instruction are delivered with the Monitor.
6-2-3-1 Monitor On-screen Menu Language
See Sony Monitor Operation Instructions.
6-2-3-2 On-screen Menu
See section “Customizing Your Monitor” in the Sony Monitor Operating Instruction on how to make
numerous adjustments to the monitor, by using the on-screen menu.
6-2-3-3 Brightness and Contrast
1.) See step “Adjusting the brightness and contrast” section “Customizing Your Monitor” in the Sony
Monitor Operating Instruction.
2.) To calibrate the monitor so that it is capable for diagnostic medical usage set the Contrast value to
85 and the Brightness to a value from 50-80.
6-2-3-4 Centering of the Picture
See step “Adjusting the centering of the picture (CENT)” section “Customizing Your Monitor” in the Sony
Monitor Operating Instruction.
6-2-3-5 Picture Size
See step “Adjusting the size of the picture (SIZE)” section “Customizing Your Monitor” in the Sony
Monitor Operating Instruction.
6-2-3-6 Picture Zoom
See step “Enlarging or reducing the picture (ZOOM)” section “Customizing Your Monitor” in the Sony
Monitor Operating Instruction.
6-2-3-7 Shape of Picture
See step “Adjusting the shape of the picture (GEOM)” section “Customizing Your Monitor” in the Sony
Monitor Operating Instruction.
6-2-3-8 Color
1.) See step “Adjusting the color of the picture (COLOR)” section “Customizing Your Monitor” in the
Sony Monitor Operating Instruction.
2.) To calibrate the monitor so that it is capable for diagnostic medical usage set the Color temperature
to 9300 K.
6-2-3-9 Convergence
See step “Adjusting the convergence (CONV)” section “Customizing Your Monitor” in the Sony Monitor
Operating Instruction.
6-2-3-10 Additional settings
See step “Additional settings (OPTION)” section “Customizing Your Monitor” in the Sony Monitor
Operating Instruction.
WARNING
WARNING
Allow the monitor to warm up at least 20 minutes before making adjustment.
