IRECTION 5184024-100, REVISION 5 LOGIQWORKS® BASIC SERVICE MANUAL
Chapter 5 Components and Functions (Theory) 5-25
26
Press ALT + S, L when in viewing.
Load selected study for viewing (and
replace current loaded study)
27
Press ALT + S, A when in viewing.
Add study (load selected study to compare
with currently loaded study):
28
Press ALT + I, C, U when in viewing. Select up direction for cine.
29
Press ALT + I, C, D when in viewing. Select down direction for cine.
30
Press ALT + I, C, B when in viewing. Select bounce for cine.
31
Press ALT + I, F, H when in viewing. Flip image horizontally.
32
Press ALT + I, F, V when in viewing. Flip image vertically.
33
Press ALT + I, F, L when in viewing. Rotate 90° to left.
34
Press ALT + I, F, R when in viewing. Rotate 90° to right.
35
Press ALT + I, A, C, M when in viewing. Create marker.
36
Press ALT + I, A, C, T when in viewing. Create annotation text.
37
Press ALT + I, A, C, D when in viewing. Create distance indicator.
38
Press ALT + I, A, O when in viewing.
Show image annotation (if previously
created).
39
Press ALT + I, Q, L when in viewing. Select linear interpolation for zoom.
40
Press ALT + I, W, I when in viewing. Invert image.
41
Press ALT + I, W, R when in viewing. Create ROI for windowing.
42
Press ALT + I, W, T, L when in viewing. Select linear windowing function.
43
Press ALT + I, W, T, E when in viewing. Select exponential windowing function.
44
Press ALT + I, W, T, O when in viewing. Select logarithmic windowing function.
45
Press ALT + I, W, T, when in viewing. Select sigmoid windowing function.
46
Press ALT + I, F, Right Arrow then Down
Arrow plus [Enter] when in viewing.
Select image filter option.
47
Press ALT + I, C, C, Right Arrow when in
viewing.
Select cutlines option.
48
Press ALT + S, P when in viewing. Load previous study in selection.
49
Press ALT + S, N when in viewing. Load next study in selection.
50
Press ALT + S, B when in viewing. Go back to Data Selector.
51
Press ALT + I, Z, 1 thru 4 followed by
[Enter] when in viewing.
Select zoom factor of 1 to 4
52
Press ALT + I, Z, T when in viewing. Show images at true size
53
Press ALT + I, Z, M when in viewing. Create magnifying glass.
Table 5-6 Overview of LOGIQworks Shortcut checks
Step
Check Expected Result
