Brake--Vacuum booster assembly
140
10. Connect brake main pump
Assemble U-shaped joint pin in U-shaped joint and brake pedal, and assemble fixing clamp to U-shaped
joint pin.
11. Assemble brake main pump
12. Assemble carbon canister assembly [4G18-1129020]
13. Assemble air filter assembly [64000033]
14. Add brake liquid in liquid storage tank
15. Discharge the air in brake main pump
16. Discharge the air in brake system
17. Check and adjust the height of brake pedal
18. Check the pedal free travel
19. Check the height from pedal to floor
20. Check the liquid level in storage tank
21. Check whether the brake liquid leaks
