Parking brake--Parking rear brake pull cable assembly
23. Assemble parking brake shoe adjustor.
24. Assemble drag lever of parking brake shoe (LH).
25. Check the assembly of parking brake.
26. Assemble rear brake.
27. Adjust the clearance of parking brake shoe.
28. Connect brake branch pump bracket assembly.
29. Assemble rear wheels.
Torque: 103
±±
±±
± 10 N
⋅⋅
⋅⋅
⋅m
30. Check the travel of parking brake lever.
31. Adjust the travel of parking brake lever.
32. Check whether exhaust system leaks.
160
