Third gear
Put input shaft assembly into position with pressure machine
liking that shown in figure, at the same time, hold the lower
end of input shaft to disassemble gear cover, gear hub and
five gear.
Check the axial clearance of forth gear, its standard value is:
0.1—0.55mm.
Take down clip spring used by shaft with clip spring wrench.
Take out fixing ball with magnetic stick, and take down the
gear and third-and-forth synchronous gear loop.
Transmission—Disassemble assembly
170
