Take our elastic cylindrical pin from shift swing lever with pin
taker and hand hammer liking that shown in figure.
Note: do not hurt its surface.
Take down clip spring liking that shown in figure.
Disassemble interlocking bracket, shift swing lever, spring and
A gasket liking that shown in figure.
Disassemble shift swing lever and connecting bolt.
Disassemble clip spring liking that shown in figure, and dis-
connect it.
Transmission—Disassemble assembly
172
