Assemble lubricating oil pipe liking that shown in figure.
Press a new fork shaft clip spring in third and forth gear fork
shaft liking that in figure.
Assemble reverse gear block and fork shaft clip spring liking
that shown in figure.
Assemble third and forth gear fork shaft in clutch shell body,
and assemble third and forth shift fork in gear cover slot and
tighten them.
Bolt torque is 16N•m
Transmission—Disassemble assembly
186
