Gemsy GEM1900A - Page 126

序号
NO.
图号 REF NO.
名称
DESCRIPTION
数量
AMT
注解
NOTE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
29
30
31
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
124- 04-24
509- 14-02
508- 14-03
21-0 65101 10-01
508- 14-05
508- 14-06
501- 05-07
501- 04-21
502- 04-20
501- 07-21 -00
501- 07-29
501- 07-63
11-1 00602 20-02
501- 07-21
501- 07-37
11-4 00904 25-01
501- 07-30
501- 07-28
501- 07-27
501- 07-26
11-7 01104 20-01
21-0 45080 80-01
11-4 01107 25-01
501- 07-32
501- 07-31
501- 07-46
508- 14-34
508- 14-35
16-4 03008 25-02
508- 14-37
505- 22-11
508- 02-75
12-4 06012 25-01
12-6 03005 20-01
12-6 06018 22-01
25-0 50000 00-09
501- 05-13
12-1 04006 20-01
508- 14-46
508- 14-47
508- 14-48
508- 14-49
16-6 04008 22-02
508- 14-51
16-4 03006 25-02
25-0 40000 00-09
508- 14-54
机针 DPX 5 14#
电磁阀连 线
摆杆
垫圈Φ6. 5XΦ11X1
铰链螺钉 D =12 H=1 5
拨线连接 板
拨线杆
梭床盖
摆梭
针板组件
剪线杠杆 轴
针板孔
螺钉3/3 2-56 L= 2.2
针板
定刀
固定刀螺 钉
动刀连杆
剪线杠杆 套
剪线杠杆 组件(小)
剪线杠杆 组件(大)
螺钉11/ 64-40 L =4.0
垫圈Φ4. 5XΦ8X0. 8
螺钉11/ 64-40 L =7
动刀垫圈
动刀组件
动刀螺钉 D =5.0 H= 0.9
电磁铁组 件
电磁阀安 装板
螺钉 M3X 8
衬套
限位弹簧
针杆过线 环
电磁铁安 装板螺钉M6 X12
支针螺钉M 3X5
螺钉M6X 18
卡簧C5
拨线钩铰 链螺钉
螺钉M4X 6
连接板
弹簧
拉杆
销
螺栓M4X 8
开口销
螺钉M3X 6
卡簧 C4
拉杆
Needle Dpx5 14#
Solenoid Relay Cable Asm.
Connecting Arm B
Washer 6.5x11x1
Shoulder Screw D=12 H=15
Wiper Connecting Plate B
Wiper Asm.
Inner Hook Presser Asm.,b
Shuttle
Needle Plate Asm.,a
Thread Cutter Lever Shaft
Needle Hole Guide
Screw 3/32-56 L=2.2
Needle Plate
Fixing Knife
Screw 9/64-40 L=35
Moving Knife Link
Thread Cutting Lever Ring
Thread Cutter Lever Asm.,smal
Thread Cutter Lever Asm., Larg
Screw 11/64-40 L=4.0
Washer4.5x8x0.8
Screw 11/64-40 L=7
Moving Knife Washer C
Moving Knife Asm.
Hinge Screw D=5.0 H=0.9
Solenoid For Pick Up Asm.
Solenoid Installing Base
Screw M3x8
Bush
Vertical Feed Shaft Spring
Needle Bar Thread Guide
Screw M6 L=12
Screw M3 L=5
Screw M6 L=18
Retaining Ring
Hinge Screw D=6.35 H=2.1
Screw M4 L=6
Connecting Link Guide
Spring
Driving Bar B
Pin
Bolt M4x8
Split Pin
Screw M3 L=6
C-ring
Work Clamp Connecting Link
14.1901A专用部件 Exclusive Parts For 1901A (1)
116
1
1
1
1
1
1
1
1
1
1
1
1
2
-1
1
1
1
1
1
1
1
1
1
1
1
-1
1
1
4
1
2
1
3
1
1
1
1
4
1
1
1
1
2
1
2
2
1
