SC201(1900A/1903A) Operation Instruction
27
indication becomes 0.0.
Traveling amount in Y direction can be
set in 0.1mm unit. Set -1.0 with or key.
9) Press key to finalize the setting.
10) Press key.
Pattern register mode is finalized.
11) Press key.
Mode setting is finalized and the mode returns to the normal mode.
2. Sewing
Operation Example: After perform sewing of the contents of the register P2, perform sewing
with the contents of P3.
To Next Page
