Operation Instruction SC201(1900A/1903A)
26
6) Press and set as follows with or key.
X Scale rate : 50%,
Y Scale rate : 80%,
Max speed limitation :
“2000” rpm
Thread Tension “50”
7）Press key and “X Scale rate ”
indication becomes 0.0.
Traveling amount in X direction can be
set in 0.1mm unit. Set 0.5 with or key.
8) Press key and “Y Scale rate ”
