GW Instek GDS-2000E Series User Manual

CONFIGURATION
103
Select Display Graticule
Panel Operation
1. Press the Display menu key.
Display
2. Press Graticule from the bottom
menu.
3. From the side menu choose the
graticule display type.
Full : Shows the full grid; X and Y axis
for each division.
Grid : Show the full grid without the X
and Y axis.
Cross Hair : Shows only the center X
and Y frame.
Frame : Shows only the outer frame.
