Page #279 background imageLoading...
Page #279 background image
APPENDIX
279
GTP-200B-4
Applicable to: GDS-2202E & GDS-2204E
Position X10
Attenuation Ratio
10:1
Bandwidth
DC to 200MHz
Input Resistance
10Mwhen used with oscilloscopes
with 1M input.
Input Capacitance
10.5pF to 17.5pF
Compensation Range
5pF to 30pF
Max. Input Voltage
600V DC + ACpk
Position X1
Attenuation Ratio
1:1
Bandwidth
DC to 10MHz
Input Resistance
1M(oscilloscope input resistance)
Input Capacitance
65pF to 105pF
Max. Input Voltage
200V DC + ACpk
Operating Cond.
Temperature
10°C to 50° C
Relative Humidity
85%
