SAVE/RECALL
223
Save
File Type/Source/Destination
Item
Source
Destination
Panel Setup
(DSxxxx.set)
Front panel
settings
Internal memory: Set1 ~
Set20
File system: Disk, USB
Waveform Data
(DSxxxx.csv)
(DSxxxx.lsf)
(CH1~CH4.lsf,
Ref1~Ref4.lsf,
Math.lsf)*
ALLxxxx.csv
Channel 1 ~ 4
Math operation
result
Reference
waveform Ref1~4
All displayed
waveforms
Internal memory:
Reference waveform
Ref1~4, Wave1 ~ Wave20
File system: Disk, USB
Display Image
(DSxxxx.bmp/png)
(Axxx1.bmp/png)**
Display image
File system: Disk, USB
*Stored in ALLXXXX directories when All Displayed waveforms are
saved.
**Stored in ALLXXXX directories when the Hardcopy key is
assigned to save Waveform, Setup or All.
Note: By default all filenames/directories are named
DSxxxx/ALLxxxx where xxxx is a number starting from 0001 and is
incremented by one after each save.
