GW Instek GDS-2000E Series - Save Setup

SAVE/RECALL
229
Save Setup
Panel Operation
1. To saving to an external USB
flash drive connect the drive to
the front or rear panel USB port.
If a USB drive is not connected,
files can be saved to the internal
memory.
Front Panel
2V
2. Press the Save/Recall key from the
front panel.
Save/Recall
3. Press Save Setup from the bottom
menu.
4. Press To (internal memory) or To
File and choose a destination to
save to.
To
Set1~Set20
To File
DSxxxx.set
5. Press Save to confirm saving. When
completed, a message appears at
the bottom of the display.
6. If you are saving to a file, a file utility appears
where you will be able to edit the name of the
file from the default “DSxxxx” filename.
7. To edit the filename, use the Variable knob to
highlight a character.
