CONFIGURATION
179
Copying Search Event To/From Trigger Events
Background
As the trigger system and search feature have
similar settings, their settings can be used
interchangeably by using the Copy functions.
Interchangeable
Settings
Edge, Pulse Width, Pulse Runt, Rise and Fall Times,
Bus (FFT Peak has no trigger equivalent)
Panel Operation
1. Press Search from the lower bezel
menu.
2. To copy the settings of the selected
search type to the trigger settings,
select Copy Search Settings to
Trigger.
3. To copy over the current trigger
settings to the search settings,
press Copy Trigger Settings To
Search.
Note
If the settings cannot be copied or if the there are no
trigger settings configured (so that you cannot copy
from the trigger settings), then those particular
options will not be available.
Search Event Navigation
Background
When using the search feature, each event can be
searched for according to the event settings.
Operation
1. Turn Search on and set the
appropriate search type.
177
