11. Press Trigger When from the side
menu to choose the triggering
condition for the data.
When
=, ≠, <, >, ≤, ≥
12. The bus will now trigger when the specified
data matches the Trigger When conditions.
Common Bus Trigger Settings
Bus Trigger Mode
Trigger Mode
1. Like the other trigger configurations, the Bus
Trigger mode can be set to Auto (Untriggered
Roll) and Normal.
2. Press Mode from the bottom menu
to change the triggering mode.
3. Use the side panel to select Auto or
Normal triggering modes.
Range
Auto, Normal
