GDS-2000E Series User Manual
180
2. Search events are marked by hollow white
triangles at the top of the graticule.
3. Use the search arrow keys to move between
each search event.
Search events can be navigated in both stop and
run mode.
When using the arrow keys to navigate to each
event, the “current event” will always be
centered on the display.
Save Search Marks
The search events can be saved to the graticule
display, allowing you to superimpose new search
events. Search events are saved over the entire
record length, with a maximum of 1000 marks.
1. Press Search from the lower bezel
menu.
2. Press the Save All Marks soft-key.
3. The search event markers will
become solid white triangles to
indicate that they have been saved.
