GDS-2000E Series User Manual
74
Figure
Adds a value to the expression.
Figure
Integers, floating point, or floating
point with exponent values.
Measurement
Adds automatic measurements to the expression.
Not all automatic measurements are supported.
Measurement
Pk-Pk, Max, Min, Amp, High,
Low, Mean, CycleMean, RMS,
CycleRMS, Area, CycleArea,
ROVShoot, FOVShoot, Freq,
Period, Rise, Fall, PosWidth,
NegWidth, Dutycycle, FRR, FRF,
FFR, FFF, LRR, LRF, LFR, LFF,
Phase, RPRFShoot, FPREShoot,
+Pulses, -Pulses, +Edges, -Edges
Advanced Math Operation
Panel Operation
7. Press the Math key.
M
MATH
8. Press Advanced Math from the
bottom menu.
9. Press Edit Expression.
10. The Edit f(x) screen appears. CH1 + CH2 is
shown in the expression box as an example at
startup.
