GW Instek GDS-2000E Series User Manual

REMOTE CONTROL CONFIG
255
Press Backspace to delete a
character.
Press Save Now to save the
configuration. Complete will be
displayed when successful.
Configure Socket Server
The GDS-2000E supports socket server functionality for direct two-
way communication with a client PC or device over LAN. By
default, the Socket Server is off.
Configure Socket
Server
1. Configure the IP address for the
GDS-2000E.
Page 253
2. Press the Utility key.
Utility
3. Press I/O from the bottom menu.
4. Press Socket Server from the side
menu.
5. Press Select Port and choose the
port number with the Variable
knob.
Range
1024~65535
6. Press Set Port to confirm the port
number.
7. The Current Port icon will update
to the new port number.
