GW Instek GDS-2000E Series User Manual

REMOTE CONTROL CONFIG
251
Interface Configuration
Configure USB Interface
USB
Configuration
PC side connector
Type A, host
GDS-2000E side
connector
Type B, device
Speed
1.1/2.0
USB Class
CDC (communications device
class)
Panel Operation
1. Press the Utility key.
Utility
2. Press I/O from the bottom menu.
3. Press USB Device Port from the side
menu and select Computer.
4. Connect the USB cable to the rear
panel device port.
5. When the PC asks for the USB driver, select the
USB driver included on the accompanying User
Manual CD or download the driver from the
GW Instek website, www.gwinstek.com, in the
GDS-2000E Download section. The driver
automatically sets the GDS-2000E as a serial
COM port (Shown as VPO in the PORTS node).
