Common
Vertical
Sensitivity
Resolution
8 bit
:1mV*~10V/div
*: When the vertical scale is set to 1mV/div, the
bandwidth limit will be set to 20MHz
automatically.
Input Coupling
AC, DC, GND
Input
Impedance
1MΩ// 16pF approx.
DC Gain
Accuracy*
1mV: ±5% full scale
≥2mV: ±3% full scale
Polarity
Normal & Invert
Maximum
Input Voltage
300Vrms, CAT I
Offset Position
Range
1mV/div ~ 20mV/div : ±0.5V
50mV/div ~ 200mV/div : ±5V
500mV/div ~ 2V/div : ±25V
5V/div ~ 10V/div : ±250V
Waveform
Signal Process
+, -, ×, ÷, FFT, FFTrms, User Defined Expression
FFT: Spectral magnitude. Set FFT Vertical Scale to
Linear RMS or dBV RMS, and FFT Window to
Rectangular, Hamming, Hanning, or Blackman-
Harris.
Trigger
Source
CH1, CH2, CH3*, CH4*, Line, EXT**
*four channel models only.
**two channel models only.
Trigger Mode
Auto (supports Roll Mode for 100 ms/div and
slower), Normal, Single Sequence
Trigger Type
Edge, Pulse Width(Glitch), Video, Pulse Runt, Rise
& Fall(Slope), Timeout, Alternate, Event-
Delay(1~65535 events), Time-Delay(Duration,
4nS~10S), Bus
Holdoff range
4nS to 10S
Coupling
AC, DC, LF rej., Hf rej., Noise rej.
Sensitivity
1div
External
Trigger
Range
±15V
Sensitivity
DC ~ 100MHz Approx. 100mV
100MHz ~ 200MHz Approx. 150mV
Input
Impedance
1MΩ±3%~16pF
Horizontal
Time base
Range
1ns/div ~ 100s/div (1-2-5 increments)
ROLL: 100ms/div ~ 100s/div
